OAS DV embedding - Access to font has been blocked by by CORS policy

BrandonH · February 4

I think you need to engage whoever manages sandbox.pc.com, do they have a webserver and can they set headers? There will be additional things that need to be set after you clear the first blocker with the fonts mentioned above.

If sandbox.com or devbi can use an F5 it can be done at that layer, see something like: https://community.f5.com/discussions/technicalforum/access-control-allow-origin-on-f5/54171

Rav Singh · February 5

@SteveF-Oracle

Thank you. I tried both things but no luck.

I had also tried adding the FilesMatch in httpd.conf and ssl.conf.

Other files (.gif, .css, .js) do not get this issue.

For example:

https://bidev.pc.com/dv/static/obitech-common/0.1.0.03a5a3897475/images/redwood_progress.gif (200 OK)

The Location in the Response Headers for .woff and .ttf files is https://sandbox.pc.com/saml-sso?SAMLRequest=fZFba4NAEIX%2Fiuy7……. as if it cannot get the SAML session; Status Code is 302. Whereas other files get 200.

BrandonH · February 5

When getting a 200 OK, it may simply mean that is not subject to CORS. Due to it not crossing origins. When you provided the blocked get request, we can see its crossing origins from sandbox.pc.com to bidev.pc.com as I show below. It also shows the referrer. If you provide the successful request info similar to below it may better inform us why the .woff fails.

For the successful font request & blocked woff requests please share more details including:

-Request headers

-Response headers

-Initiator chain eg:

Rav Singh · February 5

@BrandonH

Successful .gif

Request Headers

GET /dv/static/obitech-common/0.1.0.03a5a3897475/images/redwood_progress.gif HTTP/1.1

Accept: image/avif,image/webp,image/apng,image/svg+xml,image/*,*/*;q=0.8

Accept-Encoding: gzip, deflate, br, zstd Accept-Language: en-US,en;q=0.9

Connection: keep-alive

Cookie: JSESSIONID=K73X9xBZw_lT-3kYTHMInlayIOmB39czuPuX6-5do087mHTUHaW7!7565341; _WL_AUTHCOOKIE_JSESSIONID=DBtO7.byFVQSMabAi.Tc; BIGipServerBIDEV.PC.COM_POOL_6443=!VhVlZNeqASOWxiU7LFMgJbLrG7tgBoWrHf6xgSmjtZZdBrcuPRYrOUzj51MhOAxIIO2OOA27SDpfQw==; _gid=GA1.2.1336555533.1738790036; _gat_UA-30325608-8=1; _sfid_a769={%22anonymousId%22:%225570374727a127d2%22%2C%22consents%22:[]}; _ga=GA1.2.1537657441.1738790036; _evga_2def={%22uuid%22:%225570374727a127d2%22%2C%22puid%22:%22GVdFDxSWpmJIngemjfeMd3wvL0rOPi62vkjkOYvxqQMmmjlaBcMf9FB7O09G6DpOAE8bbVXPuR38gFGvON_Ea6EXyA8ruBQJ_fYFE21xjmo%22%2C%22affinityId%22:%2201K%22}; _ga_2LL237F0ZT=GS1.1.1738790036.1.0.1738790044.0.0.0; _shibsession_bidev=_ad55a2fc40d31755719980d2884f7e04

Host: bidev.pc.com

Referer: https://bidev.pc.com/dv/static/obitech-common/0.1.0.03a5a3897475/bootstraphelperbasestyles.css

Sec-Fetch-Dest: image

Sec-Fetch-Mode: no-cors

Sec-Fetch-Site: same-site

User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/132.0.0.0 Safari/537.36

sec-ch-ua: "Not A(Brand";v="8", "Chromium";v="132", "Google Chrome";v="132"

sec-ch-ua-mobile: ?0

sec-ch-ua-platform: "Windows"

Response Headers

HTTP/1.1 200 OK

Date: Wed, 05 Feb 2025 21:14:53 GMT

Server: Apache

Strict-Transport-Security: max-age=63072000; includeSubdomains

Cache-Control: public

Content-Type: image/gif

X-ORACLE-DMS-ECID: b49ae8a8-7651-47c5-9738-3dc0d33a6096-00000708

X-ORACLE-DMS-RID: 0

Vary: Origin,X-Forwarded-Proto,WL-Proxy-SSL

Expires: Wed, 04 Feb 2026 21:14:53 GMT

Strict-Transport-Security: max-age=31536000; includeSubdomains

Keep-Alive: timeout=5, max=95 Connection:

Keep-Alive Transfer-Encoding: chunked

Initiator Chain:

Blocked .woff

Request Headers

GET /dv/static/application/1.0.0.39f2e3555343/obitech-application/fonts/OracleSansUI_W_Bd.woff HTTP/1.1

Accept: */* Accept-Encoding: gzip, deflate, br, zstd

Accept-Language: en-US,en;q=0.9

Connection: keep-alive

Host: bidev.pc.com

Origin:

Referer: https://bidev.pc.com/dv/static/application/1.0.0.39f2e3555343/application.css

Sec-Fetch-Dest: font

Sec-Fetch-Mode: cors

Sec-Fetch-Site: same-site

User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/132.0.0.0 Safari/537.36

sec-ch-ua: "Not A(Brand";v="8", "Chromium";v="132", "Google Chrome";v="132"

sec-ch-ua-mobile: ?0

sec-ch-ua-platform: "Windows"

Response Headers

HTTP/1.1 302 Found

Date: Wed, 05 Feb 2025 21:14:53 GMT Server: Apache

Strict-Transport-Security: max-age=63072000; includeSubdomains

Set-Cookie: _opensaml_req_ss%3Amem%3Aee330b6b05c0de956ad9fcc27a07376338f4821689f06db1383ef2680fce6986=_419cf35c7cdbde11e1f83c9d014835fb; path=/; secure; HttpOnly; SameSite=None

Expires: Wed, 01 Jan 1997 12:00:00 GMT

Cache-Control: private,no-store,no-cache,max-age=0

Location: https://sandbox.pc.com/saml-sso?SAMLRequest=fZFbT4NAEIX%2FCtn3cmuJ..WkoA%2B%2BmGUZZB...5NLQ%2Fw3gMa69Q2EullEJ...cWJvBjpDsDP7FIJNloU7%2FQWfHkwFBrGQTkteZt%2BDVNOB3...GSRMS3%2FWDietP3CD3Pe.XElZCnk2%2B1CilGE9..5bC%2BK..klVI%2FinFTeN%2B..Glf%2B%2Fjr6Ag%3D%3D&RelayState=ss%3Amem%3Ae..86&SigAlg=http%3A%2F%2Fwww.w3.org%2F2001%2F04%2Fxmldsig-more%23rsa-sha256&Signature=GjjYeC...D0d0%2FqXOJX%2BKMUw1jA%2FK%2B%...Q%2F8FOEtC%2B1..4x%2B...A%2BV...ip%2F..p0%2B...sg%3D%3D

Content-Length: 1239

Keep-Alive: timeout=5, max=100

Connection: Keep-Alive

Content-Type: text/html; charset=iso-8859-1

Set-Cookie: BIGipServerBIDEV.PC.COM_POOL_6443=!MQ3Rllmn/0VWYmg7LFMgJbLrG7tgBrOVBe3tRqRYXLFMAirKmYYKE4hhGubl6d+WtShup2RpjtCWsQ==; path=/; Httponly; Secure

Initiator Chain

Rav Singh · February 5

Sec-Fetch-Mode: - this is set as "no-cors" for .gif and "cors" from .woff.

Where is this value set? Would it be the weblogic application which has the .woff file?

And other files like .css (https://bidev.pc.com/dv/static/oracle-jet/11.1.10.39f2e3555343/ojs/styles/alta/alta.css) have

sec-fetch-mode:cors

but also have

access-control-allow-origin:https://sandbox.pc.com set in Response Headers, so they are not blocked.

SteveF-Oracle · February 7

Hi Rav,
I agree with you about the .css file, and the root cause assessment about the auth for the static files being blocked.
I am glad you found a solution.
(btw, you may want to edit one of your posts where you exposed your real host name ;-))

I know we proposed some potential solutions based on the limited information.

These solutions generally are specific to the architecture.
For example, I proposed a potential .htaccess / virtual host
Other potential possibilities could include.

This allows Access-Control-Allow-Origin only for the allowed matched domain and subdomains

<IfModule mod_headers.c>
    SetEnvIf Origin "https://(www|sub1|sub2|sub3).domain.com$" ACAO=$0
    Header set Access-Control-Allow-Origin "%{ACAO}e" env=ACAO
    Header set Access-Control-Allow-Methods "GET"
</IfModule>

For future readers, there may not be a "one size fits all" type solution.

I will make your solution, as 'answered' for this thread.
